Telehandlers 3106 - THE COMPACT POWERHOUSE
With its combination of compact external dimensions and a high payload and engine power, the 3106 telehandler is the compact powerhouse in the Kramer portfolio. The telehandler lifts up to 3,100 kg to a maximum stacking height of 5.83 m. The Deutz engine with a maximum output of 82 kW / 112 hp ensures high machine agility and performance. The extensive standard equipment includes a top speed of 40 km/h, a reversible fan with automatic function and four steering modes with automatic synchronization.
Telehandlers 3106
Benefits at a glance
- Engine: Powerful Deutz 2.9 liter engine with a maximum performance of 82 kW (112 hp) ensures maximum productivity for demanding tasks
- Compactness: Height of 2.15 m and width of 2.09 m for applications in confined spaces
- Charging capacity: Continuous 3,100 kg payload up to a maximum stacking height of 5.83 m ensure that heavy loads are moved safely and efficiently
- Weighing system: Optional, integrated, dynamic weighing system, which enables different goods to be weighed regardless of attachment, load center of gravity and the position of the loading system
- Smart Attach: Hydraulic attachments can be changed quickly, simply, and safely as a result of the optional fully hydraulic quick change plate
Highlights
7" LCD display
- All relevant machine data at a glance summarised on the display
- Operating and setting the machine’s parameters easily and intuitively using the jog dial
- Safe jog dial operation possible, even when driving
Easy maintenance access
- Easy access to the engine compartment thanks to the wide-opening hood
- Optimum accessibility of all important components for checking fill levels
- Quick implementation of service work thanks to vertically mounted filters and additional maintenance openings
Smart Attach (fully hydraulic quickhitch system)
- Coupling of hydraulically driven attachments with the automatic connection of the hydraulic circuit, without the need to get out and in
- Increased productivity as a result of cost and time savings
- Attachments changed within seconds for full flexibility
Integrated dynamic weighing system
- Quick and easy weighing regardless of the load's center of gravity, the attachment used and the position of the loading system
- Full utilization of the capacity of transport vehicles and safe working, as overloading of trailers and machines is avoided
- Intuitive operation thanks to complete integration into the machine's operating concept
Up to 40 km/h driving speed
- Maximum speed of 40 km/h for fast and efficient relocation
- Stepless acceleration from 0 to 40 km/h without shifting gears for maximum driving comfort
Further Highlights
Height adjustable trailer hitch at the rear of the vehicle
- Easy adjustment of the coupling height to the trailer
- Maximum flexibility due to different coupling inserts
Crab steering
- Easy maneuvering in confined spaces
- Gentle driving on sensitive surfaces
- Simple control in combination with special attachments
Combined brake-inch pedal
- Simple and safe operation thanks to combined brake-inch pedal
- Wear-free regulation of the working speed even at high engine speeds
- Maximum working hydraulics even at low working speeds
Jog function
- Complete dumping of adhering material due to the jogging function
- Relief for the driver due to automatic function
- Protection of machine components through defined movements
Adjustable steering column
- Setting an ergonomically favorable position for each driver
- More space for getting in and out of the vehicle by folding away the steering wheel
Automatic central lubrication system
- Longer service life and value retention of the machine thanks to automatic lubrication of all lubrication points
- Time and cost savings thanks to low and bundled maintenance of the centralized lubrication system
- Optimum lubrication thanks to adjustable time intervals and grease quantities
Convenient entry and exit
- Comfortable entry and exit thanks to a cut-out in the cabin floor and steps arranged like stairs
- Increased safety for the driver
Reversing camera with automatic activation
- Best possible visibility in the rear area when maneuvering in tight spaces or coupling trailers
- Full all-round visibility is maintained as the camera image is integrated into the existing display
- Easy to use thanks to familiar automatic activation when reverse gear is engaged
All-wheel steering
- High stability even at full steering lock thanks to the undivided frame
- Maximum maneuverability thanks to steering angles of up to 40° on both the front and rear axles
- Consistent payload independent of the steering angle for constant leverage ratios
Front axle steering
- Safe and familiar road travel at high speed
- Precise guidance of special attachments
- Easy maneuvering in trailer mode
-
Please note that the product range may vary depending on the country.
-
The technical data of the products may vary accordingly with the selection of different options.
