Technical Data
| Engine manufacturer | Deutz |
| Drive output | 55.4 kW |
| Drive output | 75 PS |
| Cylinder capacity | 2,924 cm³ |
| Exhaust standard level | V |
| Exhaust aftertreatment | DOC / DPF |
| Engine manufacturer | Deutz |
| Drive output | 74.4 kW |
| Drive output | 101 PS |
| Cylinder capacity | 3,621 cm³ |
| Exhaust aftertreatment | DOC / DPF / SCR |
| Bucket capacity (standard bucket) | 1.05 m³ |
| Payload (max.) | 1,890 kg |
| Operating weight | 5,300 - 6,000 kg |
| Payload (S=1.25) | 2,500 kg |
| Tipping load (standard bucket) | 4,100 kg |
| Tipping load (pallet fork) | 3,200 kg |
| Tank capacity for fuel | 120 l |
| Tank capacity for hydraulic oil | 64 l |
| Travel speed Standard | 0-20 km/h |
| Travel speed Option 1 | 0-30 km/h |
| Travel speed Option 2 | 0-40 km/h |
| Differential lock | 100 % front axle + rear axle |
| Work hydraulics discharge volume (max.) | 80 l/min |
| Kinematics type | P |
| Quick change system | Kramer HV/WL-C; includes Smart Attach |
| Steering angle max. | 40 degree |
| Guaranteed sound power level LwA (cabin) | 101 dB(A) |
| Measured sound power level LwA | 98.8 dB(A) |
| Sound pressure level at the operator's ear | 74 dB(A) |
-
Vibrations (Uncertainties of measurement as specified in ISO/TR 25398:2006. Please instruct or inform the operator of possible dangers caused by vibrations.): Vibration total value of the upper extremities of the body in m/s² < 2.5 m/s² (< 8.2 feet/s²) and maximum weighted average effective value of acceleration for the body in m/s² < 0.5 m/s² (< 1.64 feet/s²) (on flat and solid ground with the corresponding driving style) and 1.28 m/s² (4.19 feet/s²) (Application in extraction under harsh environmental conditions).
-
Please note that the product range may vary depending on the country.
-
The engines shown may differ from the current delivery range in your country. Special equipment is depicted here that may be subject to extra charge. Subject to change without notice.
