Technical Data
| Drive output | 18.4 kW |
| Drive output | 25 PS |
| At max. rpm | 2,600 U/min |
| Cylinder capacity | 1,226 cm³ |
| Engine manufacturer | Yanmar |
| Exhaust aftertreatment | DOC |
| Bucket capacity (standard bucket) | 0.68 m³ |
| Payload (max.) | 1,450 kg |
| Payload at max. reach | 725 kg |
| Payload at max. stacking height | 1,450 kg |
| Stacking height (max.) | 4,301 mm |
| Payload max. (LSP 500 mm) | 1,450 kg |
| Operating weight | 3,050 - 3,350 kg |
| Thrust force (max.) | 16.4 kN |
| Lift capacity (max.) | 17.7 kN |
| Tank capacity for fuel | 33 l |
| Tank capacity for hydraulic oil | 60 l |
| Travel speed Standard | 0-20 km/h |
| Travel speed Option 1 | 0-30 km/h |
| Work hydraulics discharge volume (max.) | 36,4 l/min |
| Steering angle max. | 38 degree |
| Guaranteed sound power level LwA (operator's canopy) | 101 dB(A) |
| Measured sound power level LwA | 99.5 dB(A) |
| Sound pressure level at the operator's ear | 84 dB(A) |
-
Vibrations (Uncertainties of measurement as specified in ISO/TR 25398:2006. Please instruct or inform the operator of possible dangers caused by vibrations.): Vibration total value of the upper extremities of the body in m/s² < 2.5 m/s² (< 8.2 feet/s²) and maximum weighted average effective value of acceleration for the body in m/s² < 0.5 m/s² (< 1.64 feet/s²) (on flat and solid ground with the corresponding driving style) and 1.28 m/s² (4.19 feet/s²) (Application in extraction under harsh environmental conditions).
